Specification / Models

601

504

ElectroMed

ElectroMed

MediaMed

MediaMed

ChemMed

ChemMed

CarbonMed

CarbonMed

Service area available (ft.2) *10 ft.2 height (1)

601

504

700 - 900 ft.2

500 - 600 ft.2

600 - 800 ft.2

400 - 500 ft.2

700 - 900 ft.2

500 - 600 ft.2

600 - 800 ft.2

400 - 500 ft.2

Speed Control: 1,2,3,4,5,Auto (2)

601

504

YES

YES

YES

YES

YES

YES

YES

YES

Air Flow Rate m3/hr (cfm) (3)

Speed 1 – 5 (S1 – S5)

601

504

S1: 150 (90) / S2: 280 (167) / S3: 390 (227) / S4: 560 (334) / S5: 680 (406)

S1: 120 (72) / S2: 190 (113) / S3: 290 (173) / S4: 400 (239) / S5: 500 (299)

Service area with best performance recommend ft.2 (4)

601

504

S1: < 100 / S2: 280 / S3: 400 / S4: < 580 / S5: < 700

S1: < 80 / S2: 190 / S3: 290 / S4: < 410 / S5: < 500

Number of Air Change per hour (ACH) provide

601

504

5 Air Change per hour in 544 ft.2

5 Air Change per hour in 400 ft.2

Machine Fan Motor

601

504

Patented Extreme Silent DC Induction Bearing Fan

Patented Extreme Silent DC Induction Bearing Fan

Auto Mode Speed when determine the air quality is bad

601

504

Factory setting: Speed 3

Factory setting: Speed 3

Remote Controller / Air Monitoring Sensor / Safety Door Lock (5)

601

504

YES

YES

Programming Setting (6)

601

504

YES. Refer to MEDAIR Programming Operation Manual

YES. Refer to MEDAIR Programming Operation Manual

Light Touch LCD Display and Control (7)

601

504

YES. Light touch with finger tip and LCD display with blue light background

YES. Light touch with finger tip and LCD display with blue light background

Machine Cleaning Services Pack (8)

601

504

YES. Full set for each machine

YES. Full set for each machine

Dimension H x W x D (mm)

601

504

990 H x 425 W x 260 D (mm)

625 H x 430 W x 260 D (mm)

Weight (kg)

601

504

23

15

23

15

23

15

25

16

Noise (dB) (9)

601

504

S1: < 8 / S2: < 12 / S3: < 28 / S4: < 42 / S5: < 50

S1: < 7 / S2: < 10 / S3: < 15 / S4: < 28 / S5: < 45

Electrical Voltage and Power Cord

601

504

110 - 220V / 50-60 Hz / 1.5 meter length

110 - 220V / 50-60 Hz / 1.5 meter length

Power consumption (W) (10)

601

504

S1: < 12 / S2: < 28 / S3: < 38 / S4: < 50 / S5: < 65

S1: < 10 / S2: < 25 / S3: < 32 / S4: < 42 / S5: < 50

Filter Specification / Models

601

504

ElectroMed

ElectroMed

MediaMed

MediaMed

ChemMed

ChemMed

CarbonMed

CarbonMed

Standard Filtration Process

Washable Nano-silver Antimicrobial Pre-filter (11)

601

504

YES. Metal constructed Washable and Permanent use

YES. Metal constructed Washable and Permanent use

Photocatalytic TiO2 Filter (12)

601

504

YES. Metal constructed Honeycomb. Washable and Permanent use

YES. Metal constructed Honeycomb. Washable and Permanent use

LED UV Lamp (13)

601

504

YES. Energy saving and long lifetime LED UV: up to 40,000 hours (5 – 10 Years)

YES. Energy saving and long lifetime LED UV: up to 40,000 hours (5 – 10 Years)

Plasma Ion Generation (14)

601

504

YES. 6 x 10(6)cm3

YES. 6 x 10(6)cm3

Different models individual filtration process

Electrostatic Preceipitator remove 0.01 um fine duct particle (EP) (15)

601

504

2 EP Chamber

1 EP Chamber

True HEPA Filter remove 0.3 um fine ducts particle (16)

601

504

2 True HEPA

1 True HEPA

Honeycomb Chemical Catalytic Al. Filter (17)

601

504

2 Chemical Filter

1 Chemical Filter

Honeycomb Activated Carbon Filter (18)

601

504

2 Carbon Filter

1 Carbon Filter
